DT 4-way masking screens feature masking from the sides, top and bottom of the screen allowing and aspect image to be perfectly masked. The range of 4-way masking screens allows for solutions from the smallest of cinema rooms through to the largest of auditorium installations.
DT Dynamic 4
$999.00
On wall projector screen with 4-way motorized masking
Now Shipping
![DT Dynamic-4 Room Closed DT Dynamic-4 Room Closed](https://assets.screeninnovations.com/wp-content/uploads/2023/08/02193141/DT-Dynamic-4-Room-Closed-A.jpg)
![DT Dynamic-4 Room Closed DT Dynamic-4 Room Closed](https://assets.screeninnovations.com/wp-content/uploads/2023/08/02205352/DT-Dynamic-4-Room-Closed-B.jpg)
Mask Position Logic
The Mask Position Logic (MPL) system is a proprietary development of DT Screens and enables the Dynamic-4 to calculate the exact location that the masks should be positioned to create any requested aspect ratio in the supported range. With MPL, setting mask presets is no longer required.
![DT Dynamic-4 Closed Post Production Studio DT Dynamic-4 Closed Post Production Studio](https://assets.screeninnovations.com/wp-content/uploads/2023/08/02205334/DT-Dynamic-4-Closed-Post-Production-Studio-C.jpg)
Size
Dynamic-4
Width = Viewable Screen width + 15.75″ (400mm)
Height = Viewable Screen height + 15.75″ (400mm)
Max frame depth = 7.68″ (195mm)
Wall Surface to image Surface = 1.99″ (51mm)
Dynamic-4-L
Width = Viewable Screen width + 18″ (458mm)
Height = Viewable Screen height + 18″ (458mm)
Max frame depth = 8.11″ (206mm)
Wall Surface to image Surface = 2.36″ (60mm)
Dynamic-4-XL
Width = Viewable Screen width + 23.6″ (600mm)
Height = Viewable Screen height + 23.6″ (600mm)
Max frame depth = 9.69″ (246mm)
Wall Surface to image Surface = 3.78″ (96mm)
Color
Black Velvet
Aspect Ratios
Motorized Variable Masking – 1.33 to 2.40:1
Installation | Adjustment
Front image surface fitting – fit the frame to the wall then install the image surface
Motor
Whispertec quiet motor
(DT-DYN-4, DT-DYN-4-L only)
Power Type
120v or 230v
|
|
|
