alr for the world.
We spent three years in the lab to create a flexible, ALR screen that can go massive, and adheres to only the strictest visual acuity and uniformity standards. Most importantly – it had to be affordable.
Flexible
Thanks to its flexible chemical makeup, the multi-particle Slate material can roll tightly and stretched when necessary. That means we can utilize it in a lot of unique applications such as Zero-G®, Transformer®, and Zero Edge®. There is also the added benefit of being able to roll it on a small core for shipping simplifying logistics challenges.
large & in charge
Your Slate screen comes from a roll that is up to 189in (4800mm) tall. That equates to sizes up to 375in (9525mm) diagonally in 16:9. We can also seam the material with our proprietary micro-seaming technique, creating images nearly double that size. Imagine a 16ft tall optical screen!
Slate .8 | Slate 1.2 | Slate XL |
|
|---|---|---|---|
| Max Width | 3600″ (91440mm) | 3600″ (91440mm) | 2952″ (74980mm) |
| Max Height* | 102″ (2591mm) | 122″ (3099mm) | 184″ (4674mm) |
| Min Viewing Height | – | – | 121″ (3073mm) |
| Max Diagonal* | 200″ (3048mm) | 244″ (6451mm) | 375″ (9525mm) |
| Resolution | 8k | 8k | 4k |
| Gain | .8 | 1.2 | 1.4 |
| ALR | 70% | 65% | 60% |
| Half Gain | 30° | 35° | 37° |
| Minimum Throw | 1.5 x Image Width | 1.5 x Image Width | 1.5 x Image Width |
| Projection Type | Front Only | Front Only | Front Only |
*fixed frame
