- Lithium Rechargeable
- DC – Low Voltage
- AC
Please use our screen builder or consult with your system designer for an official specification drawing. Screen materials may expand and contract slightly over time. SI allows a 1.5% tolerance within the viewing surface.
Sizes
375: Max diagonal 110” (external mount only)
575: Max diagonal 160”
675: Max diagonal 200”
Available in standard sizes only. All dimensions are listed as seamless. Please go to our Screen Builder tool to see other standard sizes at https://dash.screeninnovations.com/screencalculator/Solo-3
Ratios
16:9
16:10
2.35:1
Colors
External – Available in White and Black color options
Flush – Available in White
Compatible power sources
Configurable in 3 available motor types:
- Lithium Rechargeable – RTS (available in 375)
- 24v DC – 485
- 110v AC* – 485
*220v AC available for international
Flexible Configuration
Configurable in 3 available motor types:
- Systems we integrate with:
SOLO 3 – 485 screens – AMX, BCP, Control4, Crestron SIMPL, Crestron Home*, Dry Contact Closures, Elan, IP*, IR, Lutron,
Loxone, RS-232*, RS-485, RTI*, Savant, URC, 0-10v, 12v Trigger
SOLO 3 – RTS screens – Alexa, Control4, Crestron SIMPL, Crestron Home*, Dry Contact Closures*, Elan, Google Home, Josh.ai*, IP*, IR*, Lutron, Loxone, RS-232*, RS-485*, RTI*, Savant, URC, 12vTrigger*
*when using a compatible gateway
Power
Configurable in 3 available motor types:
- Low voltage power with operating voltage class 2, 24–28v DC
- Power supply features include over/under-voltage, over/under current, and thermal protection for all devices in the system when used with (optional) Janus
- Electrostatic-isolated and galvanic isolation when used with (optional) Janus
- Power must be derived from a Screen Innovations-supplied power source for all low voltage and charging
Control Options
- Contact closure (optional for RTS)
- 12v trigger (optional for RTS)
- Built-in Infrared (optional for RTS)
- RF Remote (optional for 485)
- RS/RF-485 Keypad
- IP Control options (via TRO.Y/ LinkPro Z)
- Native C4 options (via C4MI)
Environment
Operating temperature range is normal ambient (32 to 110 degrees) and humidity levels up to 90%. Not meant for wet environments.
|
|
|
|
|
